Electrical Engineering Experiments 1st edition by G.P. Chhalotra – Ebook PDF Instant Download/DeliveryISBN: 9781683921158
Full download Electrical Engineering Experiments 1st edition after payment.
Product details:
ISBN-13 : 9781683921158
Author : G.P. Chhalotra
Designed as a hands-on guide for labs, the hobbyist, or for the industry professional, this book covers instructions and methods for doing experiments with currents and magnetism. It includes 49 separate experiments on electricity, magnetism, currents, voltage, generators, transformers, relays, alternators, resistance, gaps, and more. Each experiment covers: the object, method, result, and questions with answers on the experiment under discussion. A separate chapter at the end of the book has over 175 questions with answers to test your knowledge of electricity and electronics.
Electrical Engineering Experiments 1st Table of contents:
Experiment 1 To Determine Internal Resistance of a Battery
Experiment 2 Load Test on a D.C. Series Generator
Experiment 3 Load Test on a D.C. Series Motor
Experiment 4 Load Test on a D.C. Shunt Motor
Experiment 5 Load Test on a D.C. Shunt Generator
Experiment 6 Load Test on a D.C. Compound Motor
Experiment 7 Load Test on a D.C. Compound Generator
Experiment 8 No-Load Test on a Separately Excited D.C. Generator (Magnetization Characteristic)
Experiment 9 No-Load Test on a D.C. Shunt Generator (Magnetization Characteristic)
Experiment 10 No-Load Test on a D.C. Shunt Motor (Swinburne Test)
Experiment 11 To Perform a Hopkinson Test on Two Identical D.C. Shunt Machines
Experiment 12 Open-Circuit Test and Short-Circuit Test on a Single-Phase Transformer
Experiment 13 Load Test on a Single-Phase Transformer
Experiment 14 Back-to-Back Test on Two Identical Transformers (Sumpner Test)
Experiment 15 Separation of Losses in a Single-Phase Transformer (Separation of Eddy Current and Hysteresis Loss)
Experiment 16 Separation of Losses in a D.C. Shunt Motor
Experiment 17 To Perform a Load Test on a Three-Phase Slip-Ring Induction Motor
Experiment 18 To Perform a No-Load and Blocked Rotor Test on a Three-Phase Squirrel Cage Induction Motor
Experiment 19 No-Load Test and Short-Circuit Test on a Three-Phase Alternator
Experiment 20 A Load Test on a Three-Phase Synchronous Generator
Experiment 21 To Determine Regulation of a Three-Phase Alternator at Full Load, Lagging Power Factor, and Leading Power Factor
Experiment 22 To Determine the V-Curve and Inverted V-Curve of a Synchronous Motor
Experiment 23 To Determine Regulation of a Three-Phase Alternator for Full Load at a Power Factor Using the Zero Power Factor Method or the Potier Triangle Method
Experiment 24 To Determine the Regulation of a Three-Phase Alternator at a Load and Its Power Factor by the MMF Method
Experiment 25 To Measure the Iron Loss at Different Flux Densities with a Lloyd Fisher Magnetic Square
Experiment 26 Study of Overcurrent Relay (I.D.M.T. Type) and Determination of the Time-Current Characteristic
Experiment 27 Study of the Instantaneous Relay and Determination of the Pickup and Reset Values
Experiment 28 Study of the Directional Overcurrent Relay
Experiment 29 Study of the Percentage Differential Relay
Experiment 30 To Plot Burden Current Characteristics of the Given Current Transformers
Experiment 31 For the Given Current Transformer and Burden to Find the Ratio and Phase Angle Error
Experiment 32 To Plot the Power-Angle Curve of a Three-Phase Salient Pole Synchronous Generator
Experiment 33 Determination of Xd and Xq by Slip Test
Experiment 34 To Study the Effect of the Brush Separation and Brush Shift on the Speed and Power Factor of the Schrage Motor
Experiment 35 To Plot Magnetization Characteristics and Load Characteristics of Metadyne Generators
Experiment 36 To Plot the Magnetization Characteristic and Load Characteristic of an Amplidyne Generator
Experiment 37 To Determine Negative Sequence and Zero Sequence Reactions of a Synchronous Machine
Experiment 38 To Determine Parameters of a Single-Phase Induction Motor
Experiment 39 Measurement of a Small Resistance by Kelvin’s Double Bridge
Experiment 40 Calibration of a Watt-Hour Meter by a Standard Wattmeter
Experiment 41 Calibration of A.C. Wattmeter by a Standard Voltmeter and Ammeter
Experiment 42 Calibration of an Ampere-Hour Meter by a Standard Ammeter
Experiment 43 To Find an Unknown Inductance with Hay’s Bridge
Experiment 44 To Determine a Value of High Resistance by the Loss of Charge Method
Experiment 45 Calibration of a Wattmeter and Ammeter by Crompton’s Potentiometer
Experiment 46 Study of an Impulse Generator (1.6 Million Volts)
Experiment 47 To Determine the Breakdown Voltage of an Oil Sample
Experiment 48 To Determine the Breakdown Characteristics
